StarTech Accessory PIB2M21 USB to M.2 SATA Converter for Raspberry Pi and Development Boards Retail
- SKU: 194476
- Vendor: StarTech
- UPC: 065030867849
Add storage capacity to your development board
This convenient USB 2.0 to M.2 SATA converter lets you overcome data storage limitations of your development board by enabling you to connect an M.2 SATA drive through your board’s USB-A port.
A convenient integrated solution
The USB to M.2 SATA converter integrates seamlessly with your existing development board. It’s the perfect addition for development-board based applications such as surveillance, media players and servers, digital signage and IoT/automation solutions. It enables you to utilize your M.2 SATA drives with your dev board, and take advantage of the small form factor of M.2 SATA which makes it ideal for applications with space limitations.
Easy to install
Compatible with M.2 SATA drives (2230, 2242, 2260, and 2280), the converter is easy to install and doesn’t require any device driver installation. It comes with a USB cable and all mounting accessories, including standoffs, so integrating it with your Raspberry Pi is fast and easy.
StarTech.com provides industry-leading support to get you up and running quickly. The PIB2M21 is backed by a StarTech.com 2-year warranty and free lifetime technical support.
Bus Type
USB 2.0
Chipset ID
Renesas - PD720231A
Compatible Drive Types
M.2 (NGFF, B-Key)
Drive Size
22m - M.2 NGFF
Interface
USB 2.0
Number of Drives
1
Supported Drive Height(s)
2230, 2242, 2260, 2280
MTBF
5,839,751 hrs
Type and Rate
USB 2.0 - 480 Mbit/s
SATA III (6 Gbps)
Drive Connectors
1 - M.2 (NGFF, B-Key)
Host Connectors
1 - USB Micro-B (5 pin)
Other Interface(s)
1 - USB Micro-B (5 pin) (Power)
LED Indicators
1 - Activity
Power Source
USB-Powered
Humidity
15% - 90% RH
Operating Temperature
5oC to 50oC (41oF to 122oF)
Storage Temperature
-25oC to 70oC (-13oF to 158oF)
Color
Red
Item Dimension (L"xW"xH")
7 x 6 x 2
Weight
1.00 lb
Warranty Information
2 Year Warranty
