Intel Motherboard S2600WF0 XeonProcessor LBG-4 24 DIMMS up to 205W No LOM/LBG-4 Retail
- SKU: 202587
- Vendor: Intel
- UPC: 735858344470
- EAN: 5032037105255
› Dual CPU sockets with support for Intel® Xeon® Scalable processors
› Up to 24 DDR4 DIMMs
› Three riser card slots with support for up to eight PCIe* 3.0 add-in cards for high configuration flexibility
› Four on-board PCIe* OCuLink* connectors for direct attach NVMe* 2.5” SSD support
› Networking flexibility via 10G SFP+ and 10GBase-T OCP mezzanine modules
› Available in 1U and 2U systems with support for up to 24 NVMe* drives in a 2U chassis
› Support for the full line of Intel® RAID Modules
Product Collection
Intel Server Board S2600WF Family
Code Name
Products formerly Wolf Pass
Number of QPI Links
2
Compatible Product Series
Intel Xeon Scalable Processors
Board Form Factor
Custom 16.7" x 17"
Chassis Form Factor
Rack
Socket
Socket P
Integrated Systems Available
Yes
Integrated BMC with IPMI
IPMI 2.0 with OEM extensions
Rack-Friendly Board
Yes
TDP
205 W
Included Items
(1) Intel Server Board S2600WF0 with no LAN-on-Board
Embedded Options Available
No
Description
A rack optimized server board supporting two Intel Xeon processor Scalable family up to 205W 24 DIMMs and no Ethernet on board
Memory Types
DDR4 ECC RDIMM/LRDIMM 2133/2400/2666
Max of Memory Channels
12
Max of DIMMs
24
ECC Memory Supported
Yes
Integrated Graphics
No
Graphics Output
VGA
PCI Express Revision
3.0
Max of PCI Express Lanes
100
Connector for Intel Integrated RAID Module
1
Riser Slot 1: Total of Lanes
24
Riser Slot 2: Total of Lanes
24
Riser Slot 3: Total of Lanes
12
USB Revision
2.0 3.0
Number of USB Ports
8
Total number of SATA Ports
10
RAID Configuration
SW RAID 0/1/10 (5 optional)
Number of Serial Ports
2
Integrated LAN
No
Firewire
No
Integrated SAS Ports
0
Integrated InfiniBand
No
Max CPU Configuration
2
Low Halogen Options Available
See MDDS
Intel Optane Memory Supported
Yes
Intel Virtualization Technology for Directed I/O (VT-d)
Yes
Intel Remote Management Module Support
Yes
Intel Node Manager
Yes
Intel Quick Resume Technology
No
Intel Quiet System Technology
No
Intel HD Audio Technology
No
Intel Rapid Storage Technology enterprise
Yes
Intel Fast Memory Access
Yes
Intel Flex Memory Access
Yes
Intel I/O Acceleration Technology
Yes
Intel Advanced Management Technology
Yes
Intel Server Customization Technology
Yes
Intel Build Assurance Technology
Yes
Intel Efficient Power Technology
Yes
Intel Quiet Thermal Technology
Yes
TPM Version
2.0
Intel AES New Instructions
Yes
Item Dimension (L"xW"xH")
22 x 19 x 4
Weight
11.00lbs
Warranty
3-year Standard
