Product Detail

Product Collection
Intel Server Board S2600BP Family

Code Name
Products formerly Wolf Pass

Number of QPI Links
2

Compatible Product Series
Intel Xeon Scalable Processors

Compatible Product Series
Intel Xeon Scalable Processors

Chassis Form Factor
Rack

Socket
Socket P

Integrated Systems Available
No

Integrated BMC with IPMI
Yes

Rack-Friendly Board
Yes

TDP
165 W

Included Items
(1) OEM 10 pack includes (10) Intel Server Board S2600BPB

Embedded Options Available
No

Description
A high-density server board supporting two Intel Xeon Processor Scalable Family supporting dual 10GbE and 16 DIMMs with two DIMMs per Channel designed for large memory bandwidth an ideal option for high-performance computing and datacenter deployment.

Memory Types
DDR4 ECC RDIMM/LRDIMM 2133/2400/2666

Max of Memory Channels
12

Max of DIMMs
16

ECC Memory Supported
Yes

Integrated Graphics
No

Graphics Output
VGA

PCI Express Revision
3.0

Max number of PCI Express Lanes
96

Connector for Intel Integrated RAID Module
1

Riser Slot 1: Total number of Lanes
16

Riser Slot 2: Total number of Lanes
24

Riser Slot 3: Total number of Lanes
24

USB Revision
3.0

Number of USB Ports
2

Total number of SATA Ports
8

RAID Configuration
RAID Levels 0/1/10/5/50 (LSI)

Number of Serial Ports
1

Integrated LAN
2x 10GbE 1x 1GbE (Dedicated Management)

Firewire
No

Integrated SAS Ports
0

Integrated InfiniBand
No

Max CPU Configuration
2

Low Halogen Options Available
See MDDS

Intel Optane Memory Supported
Yes

Intel Optane Memory Supported
Yes

Intel Remote Management Module Support
Yes
Intel Node Manager
Yes
Intel Quick Resume Technology
No
Intel Quiet System Technology
No
Intel HD Audio Technology
No
Intel Rapid Storage Technology enterprise
Yes
Intel Fast Memory Access
Yes
Intel Flex Memory Access
Yes
Intel I/O Acceleration Technology
Yes
Intel Advanced Management Technology
Yes
Intel Server Customization Technology
Yes
Intel Build Assurance Technology
Yes
Intel Efficient Power Technology
Yes
Intel Quiet Thermal Technology
Yes
TPM Version
2.0
Intel AES New Instructions
Yes
Item Dimension (L"xW"xH")
24 x 21 x 11
Weight
34.00lbs
Warranty
3-year Standard
