Product Detail

Product Collection
Intel Server System R1000WF Family

Code Name
Products formerly Wolf Pass

Compatible Product Series
Intel Xeon Scalable Processors

Chassis Form Factor
1U Rack

Board Form Factor
Custom 16.7" x 17"

Rack Rails Included
No

Socket
Socket P

System Board
Intel Server Board S2600WFT

Target Market
Cloud/Datacenter

Rack-Friendly Board
Yes

Power Supply
1100 W

Power Supply Type
AC

Number of Power Supply Included
1

Redundant Fans
No

Redundant Power Supported
Supported, requires additional power supply

Heat Sink
(2) 1U Standard Heat Sink FXXCA78X108HS

Heat Sink Included
Yes

Backplanes
Included

Included Items
(1) Intel Server Board S2600WFT (Dual 10GbE LAN) S2600WFT, (2) Riser card assembly with 1 slot PCIe x16 riser card F1UL16RISER3, (8) 2.5 Hot-swap drive bays with drive carriers and drive blanks: Includes (1) SAS/NVMe Combo backplane F1U8X25S3PHS, (8) 2.5 hot swap drive tool less carriers FXX25HSCAR3, (1) Pre-installed Standard Control Panel assembly FXXFPANEL2, (1) Pre-installed Front I/O Panel assembly (VGA and 2 x USB), (1) 200mm Backplane I2C cable, (1) 650mm MiniSAS HD Cable AXXCBL650HDHRT, (1) 850mm MiniSAS HD Cable AXXCBL850HDHRS, (1) 400mm Backplane power cable, (1) Air duct, (6) Dual rotor system fans FR1UFAN10PW, (8) DIMM slot blanks, (1) Chassis Stiffener Bar, (1) 1100W power supply module AXX1100PCRPS, (2) CPU heat sinks FXXCA78X108HS, (2) CPU heat sink No CPU Label inserts, (2) Standard CPU Carrier, (1) Power supply bay blank insert, (2) Chassis handle (1 set) installed A2UHANDLKIT3, (2) AC Power Cord retention strap assembly

Number of Front Drives Supported
8

Front Drive Form Factor
Hot-swap 2.5"

Number of Internal Drives Supported
2

Internal Drive Form Factor
M.2 SSD

Recommended Customer Price
N/A

Description
Integrated 1U system featuring an Intel Server Board S2600WFT with Dual 10GbE LAN, eight 2.5 inch hot-swap drives, 24 DIMMs, one 1100W redundant-capable power supply, Intel OCP Module for adding additional features without losing a PCIe add-in slot

Memory Types
Registered/Load Reduced DDR4-2133/2400/2666 MHz

Max number of DIMMs
24

PCIe x24 Riser Super slot
2

Connector for Intel I/O Expansion Module x8 Gen 3
1

Connector for Intel Integrated RAID Module
1

Riser Slot 1: Included Slot Configuration(s)
1x PCIe Gen3 x16

Riser Slot 2: Included Slot Configuration(s)
1x PCIe Gen3 x16

Number of USB Ports
5

Total number of SATA Ports
10

RAID Configuration
SW RAID 0, 1, 10, optional 5

Number of Serial Ports
2

Integrated LAN
2x 10GbE

Number of LAN Ports
2

Max CPU Configuration
2
Intel Optane Memory Supported
Yes
Intel Remote Management Module Support
Yes
Integrated BMC with IPMI
IPMI 2.0 with OEM extensions
Intel Node Manager
Yes
Intel On-Demand Redundant Power
Yes
Intel Advanced Management Technology
Yes
Intel Server Customization Technology
Yes
Intel Build Assurance Technology
Yes
Intel Efficient Power Technology
Yes
Intel Quiet Thermal Technology
Yes
Intel Virtualization Technology for Directed I/O (VT-d)
Yes
Intel Rapid Storage Technology enterprise
Yes
Intel Quiet System Technology
Yes
Intel Fast Memory Access
Yes
Intel Flex Memory Access
Yes
TPM Version
Item Dimension (L"xW"xH")
39 x 23 x 10
Weight
55.00lbs
Warranty
3-year Standard
