StarTech Accessory DKT30CSDHPD Multiport Adapter USB-C 4K HDMI GbE 2xUSB3.0 Retail
- SKU: 203214
- Vendor: StarTech
- UPC: 065030872362
When coupled with your laptop display, this versatile USB-C multiport adapter makes it easy to create a dual-monitor workstation when you need it. It offers a 4K HDMI port (with audio), so you can easily connect a high-resolution monitor and gain access to more screen space. With higher resolutions, you can view more windows at once and increase your productivity.
The Gigabit Ethernet port ensures reliable wired network access, which is ideal for areas with limited Wi-Fi access. Plus, with two additional USB 3.0 ports (USB Type-A) you can connect your existing peripheral devices, like your mouse or flash drive.
The USB-C adapter also features an SD card reader slot so you can access all of your multimedia content.
Designed for easy portability
This multiport adapter means you dont have to carry multiple power adapters with you. Ideal for mobile use, it features a USB-C port that supports USB Power Delivery 2.0 (USB PD 2.0), so you can use your laptops USB-C power adapter to power both your laptop and the multiport adapter.
4K Support
Yes
Bus Type
USB-C
Chipset ID
VLI - VL813 (USB 3.0 Hub)
VLI - VL100 (USB Power Delivery)
Genesys Logic - GL857L
Parade - PS176
Realtek - RTL8153 (LAN)
Displays Supported
1
Fast-Charge Port(s)
No
Industry Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
USB 3.0 - Backward compatible with USB 2.0 and 1.1
Auto MDIX
Yes
Auto MDIX
Yes
Full Duplex Support
Yes
Maximum Data Transfer Rate
5 Gbps (USB 3.0)
2 Gbps (Ethernet Full-Duplex)
Maximum Digital Resolutions
4096 x 2160p 24Hz or 3840 x 2160p (HDMI) 30Hz
Lower resolutions are also supported. For example, if the max is 3840 x 2160p (4K), it also supports 2560 x 1600p and 2560 x 1440p.
Type and Rate
USB 3.0 - 5 Gbit/s
UASP Support
Yes
Connector Type(s
)1 - USB Type-C (24 pin) USB 3.0 Male
1 - HDMI (19 pin) Female
1 - RJ-45 Female
2 - USB Type-A (9 pin) USB 3.0 Female
1 - SD / MMC Slot Female
1 - USB-C (24 pin) USB Power Delivery only Female
OS Compatibility
Windows 7, 8, 8.1, 10
Mac OS 10.11 to 10.12
Chrome OS
Note
Not all USB-C ports support the full functionality of the USB Type-C standard. Ensure that your host USB-C port supports USB Power Delivery 2.0 and DP alt mode.
The adapter can connect to a host laptops USB-C port that doesnt support USB Power Delivery 2.0. However, in this configuration if a power adapter is connected to the multifunction adapter, it will not pass power through to your host laptop.
A 4K-capable display is required to achieve 3840 x 2160p resolution (4K is also known as 4K x 2K)
USB 3.0 is also known as USB 3.1 Gen 1 this connectivity standard offers speeds up to 5Gbps.
Your laptop might have specific charging requirements. For example, if your laptop requires exactly 60W of power and an adapter consumes some of the 60W, your laptop might not recognize that it is getting enough power. For more information about Power Delivery, refer to the manufacturer of your hardware.
System and Cable Requirements
A host laptop with an available USB-C port (to ensure full adapter functionality, the host USB-C port must support USB Power Delivery 2.0 and DP alt mode)
Power Delivery
60W
Power Source
USB-Powered
Humidity
4050% RH
Operating Temperature
0oC to 55oC (32oF to 131oF)
Storage Temperature
-10oC to 70oC (14oF to 158oF)
Cable Length
152 mm (6 in)
Color
Gray and Black
Enclosure Type
Plastic
Included in Package
1 - multiport adapter
1 - quick-start guide
Item Dimension (L"xW"xH")
6 x 7 x 2
Weight
1.00lbs
Warranty
3 Year
