StarTech AC DK30CH2DEP Triple Monitor 4K USB-C Dock with 5xUSB3.0 Ports 100W Power Delivery Retail
- SKU: 225570
- Vendor: StarTech
- UPC: 065030879996
You can also connect the dock to your USB 3.0 laptop through a USB-A port, using a USB-C to A cable, such as the USB315AC1M(sold separately). Note: Power Delivery to charge your laptop is not available through USB-A, and only dual display is supported.
Enhance Productivity
The 4K USB-C docking station lets you create a three-monitor Ultra HD workstation. Connect:
• 2x 4K DisplayPort (DisplayLink) at 4096 x 2160 resolution @ 60Hz / 3840 x 2160 @ 60Hz and
• 1x 4K HDMI (DP Alt Mode) at 4096 x 2160 resolution @ 24Hz / 3840 x 2160 @ 30Hz
For high-resolution applications, you can connect the dock to a 5K display at 60Hz, using the two DisplayPort ports.
100W Power Delivery
Using a single cable, the USB-C dock will power and charge power-hungry laptops, with up to 100W Power Delivery, and power your peripherals with its 150W power adapter.
Powerful Connections
This triple-monitor docking station lets you transform your laptop into a full-sized workstation. It gives you five USB 3.0 ports (1x USB Type-C and 4x USB Type-A incl. 1x Fast-Charge port), a Gigabit Ethernet port, headset jack, and separate 3.5 mm audio and microphone ports.
The TAA compliant DK30CH2DEP is backed by a StarTech.com 3-year warranty and free lifetime technical support.
Applications
Ideal for 4K video editing or working with high-resolution graphics
Work on multiple documents simultaneously in office applications
View multiple monitors at a glance, in financial or investment firms
Enhanced Power Delivery (100W) supports power-hungry laptops
HARDWARE
4K Support
Yes
Bus Type
USB-C
Chipset ID
DisplayLink - DL-6950
Genesys Logic - GL3523
Genesys Logic - GL3523S
Texas Instruments - TPS65982
Parade Technologies - PS176
Displays Supported
3
Fast-Charge Port(s)
Yes
Industry Standards
USB Power Delivery Specification Rev. 2.0
USB Battery Charging Specification Rev. 1.2
DisplayPort 1.2
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
USB 3.0 - Backward compatible with USB 2.0 and 1.1
PERFORMANCE
Auto MDIX
Yes
Compatible Networks
10/100/1000 Mbps
Full Duplex Support
Yes
Maximum Data Transfer Rate
5 Gbps (USB 3.0)
2 Gbps (Ethernet Full-Duplex)
Maximum Digital Resolutions
1x HDMI (DP Alt Mode) - 4096 x 2160p at 24Hz / 3840 x 2160p at 30Hz
2x DisplayPort (DisplayLink) - 4096 x 2160p at 60Hz / 3840 x 2160p at 60Hz
1x 5K DisplayPort using 2 DP video ports - 5120 x 2880 at 60Hz
Lower resolutions are also supported. For example, if the max is 3840 x 2160p (4K), it also supports 2560 x 1600p and 2560 x 1440p.
Type and Rate
USB 3.0 - 5 Gbit/s
UASP Support
Yes
CONNECTOR(S)
Connector Type(s)
2 - DisplayPort (20 pin) Female
1 - HDMI (19 pin) Female
2 - USB Type-C (24 pin) USB 3.0 (5Gbps) Female
1 - USB 3.0 A (Fast-Charge, 9 pin, SuperSpeed) Female
3 - USB Type-A (9 pin) USB 3.0 Female
1 - RJ-45 Female
1 - 3.5 mm Mini-Jack (4 Position) Female
2 - 3.5 mm Mini-Jack (3 Position) Female
1 - Security Lock Slot Female
SOFTWARE
Windows 7, 8, 8.1, 10
macOS 10.9 - 10.12, 10.14
Chrome OSTM v55+
SPECIAL NOTES / REQUIREMENTS
Note
Not all USB-C ports support the full functionality of the USB Type-C standard. Ensure that your host USB-C port supports USB Power Delivery 2.0 and DP alt mode.
4K resolution is supported on all 3 video ports. A 4K-capable display is required to achieve 4Kx2K resolution
If connected to a USB 2.0 host port, or if using a USB 2.0 host connection cable, performance may be limited (USB 3.0 host cable included)
USB 3.0 is also known as USB 3.1 Gen 1, this connectivity standard offers speeds up to 5Gbps
5K resolution is supported by connecting the two DisplayPort video ports to a single 5K display. A 5K-capable display is required to achieve 5K (5120 x 2880 60Hz) resolutions
The dock connects to the USB-C port on your laptop. The dock can also be connected to the USB-A port on laptops using a USB-C to A cable, sold separately, but only dual display is supported, and Power Delivery to charge your laptop is not available through USB-A
System and Cable Requirements
USB-C enabled computer with an available USB Type-C port
POWER
Center Tip Polarity
Positive
Input Current
2.5 A
Input Voltage
100 to 240 AC
Output Current
7.5 A
Output Voltage
20V DC
Plug Type
N
Power Delivery
100W
Power Source
AC Adapter Included
ENVIRONMENTAL
Humidity
0 to 70% RH
Operating Temperature
0oC to 40oC (32oF to 104oF)
Storage Temperature
-20oC to 60oC (-4oF to 140oF)
PHYSICAL CHARACTERISTICS
Color
Black and Silver
Enclosure Type
Plastic
WHATS IN THE BOX
Included in Package
1 - Docking Station
1 - USB-C Cable
1 - Universal Power Adapter (NA/JP, ANZ)
1 - User Manual
Item Dimension (L"xW"xH")
13 x 7 x 4
Weight
3.00 LB
Warranty Information
3 Year Warranty
