StarTech Accessory CDP2DP14UCPB USB-C to DisplayPort Adapter with Power Delivery 8K 30Hz Retail
- SKU: 241333
- Vendor: StarTech
- UPC: 065030883641
• 60W PD PASS THROUGH CHARGING: The USB-C video converter adapter allows up to 60W Power Delivery to power & charge your laptop while displaying video on a DisplayPort monitor using a single USB-C port
• COMPATIBILITY: Works w/ DP over USB Type-C (Thunderbolt 3 compatible) laptops like Lenovo ThinkPad X1 Carbon, Dell XPS 13, HP EliteBook, TB3 MacBook Pro 13 / Air, Surface Book 3/Laptop 3, Chromebook
This USB-C™ to DisplayPort™ adapter lets you connect your USB Type-C or Thunderbolt 3 device to a DisplayPort display, providing you with a convenient, high-performance solution. The adapter features USB Power Delivery so you can power and charge your devices while outputting Ultra HD video.
Power & Video with USB Power Delivery
This USB-C display adapter supports USB Power Delivery up to 60 watts and features an additional USB-C port so you can charge your laptop or tablet using its USB-C power adapter.
Incredible 8K Picture Quality
Delivering cutting-edge picture quality, this 8K DisplayPort 1.4 adapter supports UHD resolutions up to 7680x4320, and also features HBR3 functionality, providing a bandwidth of up to 32.4Gbps. With HDR support, you can enjoy lifelike images with increased contrast, brightness and colors and greater luminosity than standard digital imaging.
The DisplayPort dongle is also backward compatible with 4K and 1080p displays, which makes it a great accessory for home, office or other work environments, while future-proofing for 8K implementation.
HARDWARE
Active or Passive Adapter
Active
AV Input
USB-C
AV Output
DisplayPort - 1.4
Chipset ID
Parade PS8468
VIA VL102
Ports
1
PERFORMANCE
Audio Specifications
DisplayPort - 7.1 Channel Audio
Bandwidth
HBR3
Maximum Cable Distance To Display
6.6 ft (2 m)
Supported Resolutions
DisplayPort: 7680x4320 (8K) / 60Hz
Video Revision
DisplayPort 1.4
Wide Screen Supported
Yes
CONNECTOR(S)
Connector A
1 - USB-C (24 pin) DisplayPort Alt Mode Male Input
Connector B
1 - DisplayPort (20 pin) Female Output
1 - USB-C (24 pin) USB Power Delivery only Female Input
SOFTWARE
OS Compatibility
Windows 8, 8.1, 10
macOS 10.12 - 10.15
SPECIAL NOTES / REQUIREMENTS
System and Cable Requirements
Your USB-C port must support DisplayPort over USB-C (DP Alt Mode) in order to work with this adapter.
To achieve 8K resolutions, your source and your destination must support DisplayPort 1.4.
POWER
Power Delivery
60W
ENVIRONMENTAL
Humidity
10%-85% RH
Operating Temperature
5oC to 45oC (41oF to 113oF)
Storage Temperature
-10oC to 70oC (14oF to 158oF)
PHYSICAL CHARACTERISTICS
Color
Black
Material
Plastic
WHATS IN THE BOX
Included in Package
1 - USB-C to DisplayPort Adapter
Item Dimension (L inchxW inchxH inch)
9 x 5 x 1
Weight
1.00lb
Warranty Information
3 Year Warranty
