StarTech Accessory ST12MHDLANU HDMI and USB Over IP Distribution Kit 1080p Retail
- SKU: 183800
- Vendor: StarTech
- UPC: 065030862110
• Extends four USB peripheral devices for remote console control
• Free mobile app makes it easy to manage switching video wall control (iOS / Android / Chrome browser)
• Tidy, professional installation using the included mounting hardware
• Connect using a Gigabit LAN network
• Easy point-to-point or point-to-multipoint setup
• Extend HDMI using existing network infrastructure
• Supports video resolutions up to 1920x1080 (1080p)
Hardware
Audio
Yes
Cabling
Cat 5e UTP or better
Daisy-Chain
Yes
Output Signal
HDMI
Ports
1
Rack-Mountable
Yes
Performance
Audio Specifications
Stereo Sound
Max Distance
100 m / 330 ft
Maximum Digital Resolutions
1920x1200 at 60Hz
Supported Resolutions
1920 x 1200 (1080p)
Wide Screen Supported
Yes
Connector(s)
Connector A
1 - HDMI (19 pin) Female Input
1 - USB B (4 pin) Female
1 - RJ-45 Female
Connector B
1 - HDMI (19 pin) Female Output
4 - USB A (4 pin) Female
1 - RJ-45 Female
Indicators
LED Indicators
1 - Link OK / POWER Transmitter
1 - Reset Transmitter
1 - Link OK / POWER Receiver
1 - Reset - Receiver
Power
Center Tip Polarity
Positive
Input Current
0.6 A
Input Voltage
100 to 240 AC
Output Current
1.5 A
Output Voltage
12 DC
Plug Type
M
Power Source
AC Adapter Included
Environmental
Humidity
0% - 80 %
Operating Temperature
0oC to 40oC (32oF to 104oF)
Storage Temperature
-10oC to 60oC (14oF to 140oF)
Physical Characteristics
Color
Black
Enclosure Type
Aluminum
Whats in the Box
Included in Package
1 - HDMI over IP transmitter
1 - HDMI over IP receiver
2 - power adapters
2 screws
1 - screw driver
2 - CAT5 cables
2 - mounting brackets
1 - quick install guide
Local Unit Connectors
1 - HDMI (19 pin)
1 - RJ-45
Remote Unit Connectors
1 - HDMI (19 pin)
1 - RJ-45
Item Dimension (L inchxW inchxH inch)
12 x 10 x 4
Weight
4.28 lb
Warranty Information
2 YEARS
