Zotac System ZBOX-ECM73070C-U-W2B Core i7-10700 16GB 512GB 1TB RTX3070 Windows 10 Home Retail
- SKU: 251078
- Vendor: Zotac
- UPC: 810012082051
- EAN: 4895173622755
Empower everything in one incredibly powerful, versatile Mini PC. MAGNUS ONE boasts the ultimate performance in an all-new and compact design. It is the first Mini PC taking advantage of the ZOTAC GAMING GeForce RTX 3070 graphics card for high-fidelity ray-traced graphics and cutting-edge AI features with DLSS. Paired with a 10th Gen Intel Core i7 processor, upgradable memory and storage support, full-range connectivity options with Killer networking, MAGNUS ONE has the do-it-all capability to deliver the best experience for daily tasks, gaming, entertainment, content creation and business.
- 8.3 liter compact chassis
- 10th Gen Intel Core i7 processor
- ZOTAC GAMING GeForce RTX 3070 8GB GDDR6
- 16GB DDR4 Memory (up to 64GB)
- 512GB M.2 SSD, 1TB 2.5-inch HDD
- Windows 10 Home 64-bit pre-installed
- 1 x HDMI 2.1, 3 x DisplayPort 1.4a, 1 x HDMI 1.4 (integrated)
- 4 x USB 3.1 GEN2, 4 x USB 3.0 (1 Type-C)
- Killer WiFi, Gigabit and 2.5Gbps Ethernet
- 500W 80+ Platinum power supply
- Creator Ready / 4K Ready / Gaming Ready / VR Ready
Computing System
Processor
Intel Core i7-10700 (8-core 2.9 GHz, up to 4.8 GHz)
Chipset
Intel, NVIDIA
System Memory
16GB DDR4 (up to 64GB)
Graphics
Graphics Engine
ZOTAC GAMING GeForce RTX 3070 8GB GDDR6 256-bit
Video Output
1 x HDMI 1.4 (up to 3840x2160 at 30Hz) (integrated)
1 x HDMI 2.1 (up to 7680x4320 at 60Hz)
3 x DisplayPort 1.4a (up to 7680x4320 at 60Hz)
Up to Quad Display Support
Ultra High Speed HDMI Cable is required to support 8K/60FPS or 4K/120FPS
Storage
Hard Drive
1TB 2.5-inch HDD
Mass Storage
N/A
Optical Drive
N/A
mSATA
N/A
M.2512GB M.2 SSD, 1 x M.2 PCIe x4 SSD / Intel Optane memory slot (2242, 2280, 22110)
Card Reader
3-in-1 (SD/SDHC/SDXC)
I/O Ports
Audio
Microphone, Headphone, HDMI
USB Port
4 x USB 3.1
4 x USB 3.0 (1 Type-C)
LAN
Dual LAN (Gigabit Ethernet, 2.5Gbps Ethernet)
Antenna
Dual WiFI SMA connetor
Wifi
WiFi 6 AX1650
Bluetooth
Bluetooth 5
Legacy I/O
N/A
CIR Infrared Port
N/A
Thunderbolt
N/A
USB
N/A
IDE
N/A
VGA
N/A
Mechanical
Kensington Lock
Yes
LED Indicators
Power, HDD, WiFi
Power Supply
500W 80+ Platinum
Cooling system
Fan + Heatsink
Case Mounting
None
Miscellaneous
Supported OS
Windows 10 Home 64-bit pre-installed (Home N for Europe regions)
Accessories
2 x WiFi antenna
Power Cord (bundled cable type dependent on region)
Warranty Card
Quick Install Guide
USB drive with O/S Recovery
Nylon Cable Tie (optional)
Item Dimension (L"xW"xH")
18 x 13 x 9
Weight
16 lbs
Warranty Information
3 Years
