Product Detail

Uncompressed 4K Video
23.6-inch with 4K UHD (3840 x 2160) panel delivers four times the pixel density and three times more onscreen space than similarly sized FHD displays, resulting in sharper visuals with greater levels of detail.

ProArt Display PA24US features 12G-SDI connection, allows receiving and transmitting uncompressed up to 4K@60Hz video footage directly from camera devices with ultra-low latency.

Self Calibration
ProArt Displays now boasts an innovative self-calibration feature for the embedded colorimeter. The self-calibration is a standalone solution without any software and compatible with any operating system. You can directly complete the color calibration and scheduled color calibration functions through the OSD operation of ProArt Display. With this flexibility, you can achieve color consistency anytime and anywhere.

Enjoy true-to-life color
PA24US exceeds industry color reproduction standards with its 99% Adobe RGB and 95% DCI-P3 color gamut, and it features true 10-bit color depth to display more than 1.07 billion colors. 600 nits peak brightness to ensure the deepest blacks and brightest whites, enabling PA24US to accurately display the most minute details in shadows and bright highlights for incredibly realistic visuals.

Class-Leading Color Fidelity
Each ProArt display is factory pre-calibrated using a new, three-scale process to guarantee industry-leading color fidelity. The display then undergoes stringent testing using ASUS advanced grayscale tracking technology to ensure smoother color gradations, better uniformity and high color accuracy with a Delta E < 1 color difference value. Each grayscale level is also carefully measured and set to ensure compliance with the precise DICOM standard for medical use. [/fusion_tab] [fusion_tab title="Specifications"]

Model
ProArt Display PA24US

Display
Panel Size (inch) : 23.6
Aspect Ratio : 16:9
Display Viewing Area (H x V) : 522.43 x 293.87 mm
Display Surface : Non-Glare
Backlight Type : LED
Panel Type : IPS
Viewing Angle (CR > or equals 10, H/V) : 178^o/ 178^o
Pixel Pitch : 0.135mm
Resolution : 3840x2160
Color Space (sRGB) : 100%
Color Space (Adobe RGB) : 99%
Color Space (DCI-P3) : 95%
Brightness (HDR, Peak) : 600 cd/m2
Brightness (Typ.) : 350cd/m2
Contrast Ratio (HDR, Max) : 1,000,000:1
Contrast Ratio (Typ.) : 1000:1
Display Colors : 1073.7M (10 bit)
Response Time : 5ms(GTG)
Refresh Rate (Max) : 60Hz
HDR (High Dynamic Range) Support : HDR10
HDR (High Dynamic Range) Support : HLG
Flicker-free : Yes

Video Feature
Trace Free Technology : Yes
ProArt Preset : Standard
ProArt Preset : sRGB
ProArt Preset : Adobe RGB
ProArt Preset : DCI-P3
ProArt Preset : Rec. 2020
ProArt Preset : DICOM
ProArt Preset : Rec. 709
ProArt Preset : HDR_PQ DCI
ProArt Preset : HDR_PQ Rec2020
ProArt Preset : HDR_HLG
ProArt Preset : HDR_HLG BT2100
ProArt Preset : HDR_HLG DCI
ProArt Preset : User mode1
ProArt Preset : User mode2
ProArt Preset : User mode3
Color Temp. Selection : Yes(5 modes)
Color Adjustment : 6-axis adjustment(R,G,B,C,M,Y)
Gamma Adjustment : Yes (Support Gamma 1.8/2.0/2.2/2.4/2.6 )
Color Accuracy : Delta E< 1
ASUS ProArt Hardware Calibration : Yes
ProArt Palette : Yes
QuickFit Plus : Yes
PIP / PBP Technology : Yes
HDCP : Yes, 2.2
VRR Technology : Yes (Adaptive-Sync)
Motion Sync : Yes
HDR Preview : Yes
Low Blue Light : Yes
Multiple HDR Mode : Yes

Audio Feature
Speaker : Yes(2Wx2)

I/O Ports
12G-SDI x 1
USB-C x 1 (DP Alt Mode)
DisplayPort 1.4 x 1
HDMI(v2.0) x 2
USB Hub : 2x USB 3.2 Gen 1 Type-A
Earphone Jack : Yes
USB-C Power Delivery : 80W

Signal Frequency
Digital Signal Frequency : 15-135 KHz (H) / 48-60 Hz (V)

Power Consumption
Power Consumption : <24.1W
Power Saving Mode : <0.5W
Power Off Mode : 0W (hard switch)
Voltage : 100-240V, 50/60Hz

Mechanical Design
Tilt : Yes (+21^o to -3^o)
Swivel : Yes (+30^o to -30^o)
Pivot : Yes (+90^o to -90^o)
Height Adjustment : 0 to 130mm
Embedded Colorimeter : Yes (Support Self-Calibration)
Ambient Light Sensor : Yes
VESA Wall Mounting : 100x100mm
Kensington Lock : Yes

Accessories (varies by region)
Color pre-calibration report
DisplayPort cable
HDMI cable
Power cord
Quick release stand
Quick start guide
USB-C cable
Warranty Card
Welcome Card

Certificate
TUV Flicker-free
TUV Low Blue Light
VESA DisplayHDR 600
Calman Ready

Item Dimension (L inchxW inchxH inch)
19 x 30 x 6

Weight
25 lbs

Warranty Information
3 Years Warranty with ARR
